76-00-00
page 16
May 01/2007
Effectivity 914 Series
Edition 1 / Rev. 0
d02626
BRP-Rotax
Maintenance Manual
00209
Kommunikationsprogramm
(communicationprogram)
PC
Laptop
zur TCU
(to TCU)
zur Dekodiereinheit
(to Dongle)
Dekodereinheit
(Dongle)
zum PC
(to PC)
TCU
Fig. 76-11
