Rotax 914 series Maintenance Manual

74-00-00
page 28
May 01/2007
Effectivity 912 Series
Edition 1 / Rev. 0
d02624
BRP-Rotax
Maintenance Manual
Legend to wiring diagram (Fig. 74-20)
1 ignition magneto generator
2 trigger coil for ignition circuit ”A”
3 trigger coil for ignition circuit ”B”
4 trigger coil for rev counter
5 plug receptacle 2-pin
6 electronic rev counter
7 grounding switch for ignition circuit ”A” and ”B”
8 plug receptacle 1-pin
9 plug receptacle 4-pin
10 electronic module for ignition circuit ”A”
11 electronic module for ignition circuit ”B”
12 double ignition coil
13 engine
14 cylinder 1 - 4
15 spark plugs
16 charging coils
V consumer connection
o color code

Rotax 914 series Specifications

General

Bore	79.5 mm
Stroke	61 mm
Compression Ratio	9.0:1
Cooling System	Liquid-cooled cylinder heads, air-cooled cylinders
Redline	5800 rpm
Engine Type	4-cylinder, 4-stroke
Fuel Type	Avgas 100LL
Oil System	Dry sump
Fuel System	fuel injection
TBO (Time Between Overhauls)	2000 hours
Displacement	1.211 liters (1211 cc)
Power Output	84.6 kW (115 hp) at 5, 800 rpm
