73-00-00
page 6
October 01/2010
Effectivity 912/914 Series
Edition 1 / Rev. 3
d04777
BRP-Powertrain
Maintenance Manual
Legend:
(1) fine filter / water trap
(2) main fuel pump (MAIN)
(3) auxiliary fuel pump (AUX)
(4) check valve
(5) fuel pressure regulator
(6) inlet from the tank
(7) return line to tank
(8) fuel filter
AUX MAIN
00103
6
7
1
2
3
4
5
4
Fig. 73-2a
8
8
Fig. 73-2b
00157
