2.4) Magnetic plug
See the corresponding Maintenance Manual (Line Maintenance) for the respec-
tive engine type, 912 Series or 914 Series.
◆ NOTE: It is possible to repair the thread of the magnet plug of the
crankcase with a helicoil. See section 8.7 of the overhaul
manual.
2.5) Drain plug
See the corresponding Maintenance Manual (Line Maintenance) for the respec-
tive engine type, 912 Series or 914 Series.
2.6) Connections for instrumentation
■ CAUTION: Consult also the relevant section in the Installation Manual.
2.6.1) Oil pressure indication
Via an electric resistance pick-up attached on oil pump housing with
connection to indicating instrument.
2.6.2) Oil temperature indication
The sensor for the oil temperature is fitted in the oil pump housing. The
sensor is a thermo switch with changing internal resistance according
to oil temperature.
