10.6) Special tools and devices
See Figs. 00-9, 00-10 and 00-11.
The following tools and devices are also listed in the Illustrated Parts Catalog.
Fig. No.Part No. Description, application Number
1 276282 spark plug wrench a/f 16 ....................................... 1
276280 spark plug wrench a/f 18 ....................................... 1
2 977420 hand lever 8x130-10 .............................................. 1
for spark plug wrench
3 240880 thread bolt M8x50.................................................. 1
for crankshaft locking
4 877890 Torx bit - T40 ......................................................... 1
for magnetic plug
5 877110 guide sleeve........................................................... 1
for O-ring idle mixture screw
and idle jet
6 876510 insertion jig............................................................. 1
for oil seal (12x30x7), water pump shaft
7 877258 insertion jig for rotary seal ..................................... 1
8 877270 insertion jig assy. ................................................... 1
for oil seal 32x52x7 crankshaft magneto side
9 877802 circlip installation tool assy., .................................. 1
for assembly of piston pin circlips
10 877650 insertion jig............................................................. 1
11 - 12 877091 piston pin extractor assy. ...................................... 1
for assembly and disassembly of the piston pin
12 877155 extracting nut M6 assy., ........................................ 1
for piston pin extractor
13 276332 insertion jig assy. ................................................... 1
for pressing out needle sleeve 22x28x12
and ball bearing 15x32x8, vacuum pump
14 877276 insertion jig assy. ................................................... 1
for oil seal 22x32x7, vacuum pump
15 877360 guide sleeve........................................................... 1
for oil seal 32x52x7, crankshaft, magneto side
