Rotax MMH-912 Series User Manual

80-00-00
page 6
May 01/2007
Effectivity 912/914 Series
Edition 1 / Rev. 0
d02629
BRP-Rotax
Maintenance Manual
3.1.2) HD starter
See Fig. 80-2
Remove the 2 hex. nuts M5 (1) with lock washers (2) and washers (3)
from the rear side of the ignition cover (6). The electric starter (4) can
be removed by releasing the tension clamp (5).
05555
Fig. 80-2
6
9
5
4
1
2
3
