74-00-00
page 26
May 01/2007
Effectivity 912 Series
Edition 1 / Rev. 0
d02624
BRP-Rotax
Maintenance Manual
Legend to wiring diagram (Fig. 74-19)
1 ignition magneto generator
2 trigger coil for ignition circuit ”A”
3 trigger coil for ignition circuit ”B”
4 trigger coil for rev counter
5 plug receptacle 2-pin
6 electronic rev counter
7 grounding switch for ignition circuit ”A” and ”B”
8 plug receptacle 1-pin
9 plug receptacle 4-pin
10 electronic module for ignition circuit ”A”
11 electronic module for ignition circuit ”B”
12 double ignition coil
13 engine
14 cylinder 1 - 4
15 spark plugs
16 charging coils
V consumer connection
o color code
