Rotax MMH-912 Series - Page 73

BRP-Rotax
Maintenance Manual
Effectivity 912/914 Series
Edition 1 / Rev. 2
72-00-00
page 3
July 01/2008
d04351
3.16) Piston and cylinder assembly fitting .............................................72-00-00 / 86
3.16.1) Hydraulic valve tappets fitting ..............................................72-00-00 / 86
3.16.2) Pistons fitting .......................................................................72-00-00 / 86
3.16.3) Cylinders fitting ....................................................................72-00-00 / 90
3.16.4) Cylinder head fitting .............................................................72-00-00 / 92
3.17) Intake manifold and compensation tube assembly ......................72-00-00 / 95
3.18) Crankshaft inspection...................................................................72-00-00 / 95
4) Wear limits ..............................................................................................72-00-00 / 97
5) Form Sheets ...........................................................................................72-00-00 / 117
5.1) Form sheet for material testing ROTAX 912/914 Series ...............72-00-00 / 117
5.1.1) Inspection on cracks .............................................................72-00-00 / 117
5.1.2) Hardness test .......................................................................72-00-00 / 117
