Parameter
No.
Data
Read /
Write
Value / Range
Default
Value
78 Function for Indication contact S1 R/W
Bit 0: 0-Normally Open,
1 – Normally Closed.
Bits 1 to 15: See separate
table ‘S contact functions’.
0000
79 Function for Indication contact S2 R/W 0001
80 Function for Indication contact S3 R/W 0002
81 Function for Indication contact S4 R/W 0003
82 Position trip when function set to ‘PO’ contact S13 R/W 0-100%, 0 to 0064 h 0001
83 Position trip when function set to ‘PO’ contact S23 R/W 0-100%, 0 to 0064 h 0001
84 Position trip when function set to ‘PO’ contact S33 R/W 0-100%, 0 to 0064 h 0001
85 Position trip when function set to ‘PO’ contact S43 R/W 0-100%, 0 to 0064 h 0001
86 Function for Indication contact S54 R/W Bit 0: 0-Normally Open,
1 – normally closed.
Bits 1 to 15:
See separate table ‘S contact
functions’.
0001
87 Function for Indication contact S64 R/W 0003
88 Function for Indication contact S74 R/W 000D
89 Function for Indication contact S84 R/W 002B
90 Position trip when function set to ‘PO’ contact S53 R/W 0-100%, 0 to 0064 h 0001
91 Position trip when function set to ‘PO’ contact S63 R/W 0-100%, 0 to 0064 h 0001
92 Position trip when function set to ‘PO’ contact S73 R/W 0-100%, 0 to 0064 h 0001
93 Position trip when function set to ‘PO’ contact S83 R/W 0-100%, 0 to 0064 h 0001
94 - 96 Reserved
97 ESD direction R/W
00: Close,
01: Open,
10: Stationary
11: Ignore ESD
0000
98 ESD contact R/W
0: ESD break contact
1: ESD make contact
0000
99 ESD bypasses the actuator interlocks R/W
0: bypass disabled
1: bypass enabled
0000
100 ESD bypasses the Thermostat trip R/W
0: bypass disabled
1: bypass enabled
0000
101 ESD bypasses Local stop R/W
0: bypass disabled
1: bypass enabled
0000
102
Bits 0 to 5 - reserved
Bit 6 – Interlocks enable / disable
Bits 7 to 15 - reserved
R
0: Interlocks Enabled
1: Interlocks Disabled
0001
103 Open limit position R - 001A0000
104 Interrupter timer start limit R/W
0: Around close limit
1: Around open limit
0000
105 Interrupter timer off time R/W 1-99 secs, 0 to 0063 h 0002
106 Interrupter timer on time R/W 1-99 secs, 0 to 0063 h 0003
107 Interrupter timer activated when opening if below xx% R/W 0-100%, 0 to 0064 h 0028
108 Interrupter timer activated when closing if below xx% R/W 0-100%, 0 to 0064 h 002D
109
Bits 0 to 4 - reserved
Bit 5 – Language
Bits 6 to 15 - reserved
R
0: English
1: Alternative language
0000
110 Reserved
111 ID Main R 16 bytes ASCII -
112 ID Locals R 16 bytes ASCII -
113 ID DSM R 16 bytes ASCII -
Parameters
A4US
US
A4
US A4
US
A4
