rotork CK Series User Manual

Profibus Installation Manual
4
1 The Centronik 7
2 The Types of Profibus DP Module Option Card 8
3 The Profibus single channel NIC, showing the
network connector 9
4 The Profibus option card located in a Centronik unit 10
5 Typical Profibus DP Data Highway 12
6 Profibus Single Channel Data Highway Topology 13
7 Profibus DP Simple Dual Redundant Option
Block Diagram 14
8 Profibus DP Flying Redundancy Connection 15
9 Profibus DP System Redundancy Connection 16
10 Profibus DP RedCom Dual Redundant Option
Block Diagram 17
11 Typical Profibus DP cable specifications 19
12 Single Highway 20
13 Dual Highway SR Mode Connections 21
14 Disconnect module showing normal powered
operation - connection though to the actuator 22
15 Disconnect module showing unpowered
operation - disconnected from the actuator 22
16 Disconnect module 22
17 Input and Output Data Direction 23
18 Centronik relay outputs DO-1 to DO-4 28
19 Single Channel Profibus card LED positions 34
20 System Redundancy – Two highway redundancy 35
21 Flying Redundancy – One highway redundancy 36
22 Dual Channel Profibus card LED positions 37
23 Profibus Start Up Sequence 38
24 Limited Range Position Control and Reporting 41
25 Deadband and Hysteresis settings 41
26 Rotork DTM running in the M&M FDT container 50
27 Rotork EDD running in the Siemens PDM application 50
28 Insight 2 Software; connected to a CK actuator
using Bluetooth, viewing the actuators settings 51
29 Setting tool menu structure and PFU settable
parameters 52
