8.7 Records
In order that a replacement can be easily introduced in the
event of a device failure it is very important to record and
keep safe all the settings made for the variable registers. The
table lists all the registers that must be checked and set up
for each Profibus Module on a network. The data should be
recorded for each module.
Make a note of all changes to register settings
to ensure that, in the case of a failure, the
replacement device can be swiftly set to the
correct values.
• GSD accessed Parameters
Device Address:
Parameter
No.
Description Setting Notes
1 Limited Range Position Minimum
2 Limited Range Position Maximum
3 Deadband
4 Hysteresis
6 Motion Inhibit Time
7 Manual Movement Travel
8 Valve Jammed Time
9 Watchdog Timeout
10 Action on Loss of Comms
11 Comms Lost Position
12 Comms Fault Timer
13 Aux Input Mask
14 ESD DI-4/Net Disable
15
FR/SR mode and Simple/RedCom
redundancy
16 Part Stroke position
17 Part Stroke Limit and timeout
18 Actuator Type
• Acyclic Communications accessed Parameters
Parameter
No.
Description Setting Notes
20 Actuator Tag data
25 Permit GSD Parameterisation
Setting Up and Maintaining the Profibus
®
Module
A4US
US
A4
US A4
US
A4
