30 IQ3 Full Configuration Manual – Section: Settings
2.3.2-11 Control – Remote – Extra I/O
Remote Control
Hardwired
Control Source
Partial Stroke
Positioning
Auxiliary Mask
Analogue
Pakscan
Profibus
HART
Modbus
Extra I/O
Close Limit
Extra I/O
Fast Remotes Disabled
D17
Function Disabled
Contact N/O N/C
D18
Function Disabled
Contact N/O N/C
1/9
The DIO adds additional digital inputs and outputs to the
actuator.
Fast Remotes
Fast remotes are for modulating applications (24 VDC signals only)
Disabled
Enabled
Functions
Below is a list of functions available for each I/O:
Disabled
Remote Open
Remote Closed
Remote Maintain
Remote ESD
Open Interlock
Close Interlock
Net Disable
Partial Stroke
HandAuto
VelanReset
ConditionalOpen
ConditionalClose
Contacts
These are the default positions for the contacts which the user
can set
N/O – Normally Open Contact
N/C – Normally Closed Contact
