RTK Series 725 Annunciator

F14 - First-Up Group A

All alarms set to function F14 will operate as a single first-up group in accordance with the selected

first-up sequence. F14 is the function code allocated for first-up Group A.

FEATURE-F14 STATUS LED

Set to remove channel from first-up Group A OFF

Set to include channel in first-up Group A ON

F15 - First-Up Group B

All alarms set to function F15 will operate as a single first-up group in accordance with the selected

first-up sequence. F15 is the function code allocated for first-up Group B.

FEATURE-F15

STATUS LED

Set to remove channel from first-up Group B OFF

Set to include channel in first-up Group B ON

F16 - First-Up Group C (Four First-up Group version only)

All alarms set to function F16 will operate as a single first-up group in accordance with the selected

first-up sequence. F16 is the function code allocated for first-up Group C.

FEATURE-F16 (FOUR FIRST-UP GROUP VERSION ONLY) STATUS LED

Set to remove channel from first-up Group C OFF

Set to include channel in first-up Group C ON

F16 – Alarm Input Selection (Standard version)

On standard units that have the communications capability enabled there are only two first-up groups

A and B. On these units Function 16 is used to configure how the communications operate.

With the communications option fitted it is possible to receive alarms in the normal way, from

volt-free contacts, or via the serial communications port. This function is used to select where the

system is looking to receive this alarm information. If the function is not selected then the normal

volt-free contacts are used. If the function is selected then the serial communications port will be

monitored for details of alarm status. It is possible to set this feature on an individual channel basis

hence having some alarm channels monitoring volt-free contacts and some monitoring the

communications.

FEATURE-F16 (STANDARD VERSION) STATUS LED

Set to get alarm information from volt-free contact input OFF

Set to get alarm information from the serial communications ON

F17 - First-up Group D (Four First-up Group version only)

All alarms set to function F17 will operate as a single first-up group in accordance with the selected

first-up sequence. F17 is the function code allocated for first-up Group D.

FEATURE-F17 (FOUR FIRST-UP GROUP VERSION ONLY) STATUS LED

Set to remove channel from first-up Group D OFF

Set to include channel in first-up Group D ON
