Ruide RCS - 7. Key; 7.1 Distance Offsets

23
 Press [1] to display the input screen for the
distance and angle to the target.
 Input the values and press [SO]
Azimuth: Horizontal angle to stakeout point
VD: Vertical distance from station point to
stakeout point
 Start staking out. First Rotate the instrument
until the HAD displays as 0°00′00″. Press [Next]
 Sight the target and press [MSR] to start
measuring.
 The differences between the target position
and the stakeout point are displayed.
 Move the prism forward or backward
according to the arrowhead until all the values turn
to be 0.
 Press [ENT] to record the stakeout point.
 Press [Change] to stake out another point.
6.2 COORDINATES STAKEOUT
Input the XYZ of stakeout point, and carry on stake-out.
 In SO menu, press [2] to enter to coordinate
stakeout function.
 Input the point name and target height and
press [SO].
 Start staking out. First Rotate the instrument
until the HAD displays as 0°00′00″, press [Next]
 Sight the target and press [MSR] to start
measuring.
 The differences between the target position
and the stakeout point are displayed.
Ang/dist. SO 123
Azimuth
30°00’00”
HD
1.500
m
VD
0.5
m
R.HT
1.500
m
Back
SO
Adjust HA
HA
239°45’41”
HAD
121°13’05”
Azimuth
1°00’00”
HD
12.231
m
Cancel
Next
SO
Right
0°00’00”
Far
12.251
m
Right
0.000
m
Fill
12.231
m
Meas
Meas
1/3
Change
Coord.SO 123
Pt.N
1
R.HT
1.500
m
Input
New
Call
SO
Adjust HA
HA
239°45’41”
HAD
121°13’05”
Azimuth
36°11’24”
HD
2.231
m
Cancel
Next
