27
The calculated coordinates are shown. Enter a
PT and CD value, press [ENT] to record. The display
returns to BMS.
7.2 MEASURING ANGLE OFFSETS
In [Offset] menu, press [2] to enter angle
offset function.
If you have not taken a distance
measurement before entering this function, a
temporary measurement screen appears. Sight
the target and press [MSR].
To take the angle offset, rotate the alidade and
telescope. The measured distance (HD) remains
unchanged.
To record the offset point, press [OK]
The XYZ data is also recalculated based on the
new angle. In the dialogue box of results calculated by
the program, press [ENT] to record.
7.3 TWO-PRISM POLE
In [Offset] menu, press [3] to enter the
2Prism Pole function.
Sight the first prism and press [MSR].
Sight the second prism and press [MSR].
