Press [Detail] to view the detail of the record.
Press [DSP] to view the next page.
Press [Edit] to edit the raw data
SS：Sideshots (topo shots). All shots from the basic measurement screen are stored as SS records.
CP：Shots taken in the Angle or Repeat menus, or in the basic measurement screen.
F1/F2：Face-1 /Face-2 measurements.
Raw records contain “PT”, “HT”, “CD” and “HA/VA/SD”.
11.2 COORDINATE DATA
In Data menu press [2: Coord. Data], then coordinate data is displayed in a list, with the newest record at
the bottom of the screen. Use [▲]/[▼] to scroll through the records. (Use [ ]/[ ] to move up or down one
page), press [ENT] to see more detailed information.
The header (XYZ, YXZ, NEZ or ENZ) depends on the Coord.
Press [Detail] to view the coordinate data
Press [Find] to search the data.
Press [Add] to add a new coordinate data.
Press [Delete] in page 2 to delete the data.
UP：uploaded point coordinates
MP：manually input point coordinates
CC：points calculated in Cogo
RE：Points calculated in Resection.
SS：Sideshots, All shots from the basic measurement screen are stored as SS records.
11.3 VIEW RECORDS BY STATION
View sideshot recorded under a certain station point.
Press [3] to select STN,SS.
Station data lists are showed.
Press [▲]/[▼] to move up and down
Press [◄]/[►] to view the other pages.
Press [Delete] in page 2 to delete the station
record.
