9.2.1 AZ+HD
 Press [2] choose Direct&Distance and then
press [1] entering the AZ+HD function.
 Input the base point, azimuth, HD and VD.
 Press [OK] to calculate the coordinate.
 Press [OK] to record.
9.2.2 Store
Store function calculates a new point based on the two defined points and angle, horizontal and vertical
distances from the line defined by those two points.
 In Direct&Distance menu, press [2] entering
Store function.
 Input the two points defining the baseline
 Enter the plus-minus angle, horizontal distance,
and vertical distance from the baseline defined by
P1-P2
 Press [OK] to calculate the coordinate
 Press [OK] to record.
Direct&Distance
1.
AZ+HD
2.
Store
Cancel
AZ+HD 123
Pt N
1
Azimuth
25°00’00”
HD
1.257
m
VD
0.150
m
OK
Save 123
N
-5.408
m
E
8.565
m
Z
0.393
m
Pt.N
3
Code
A
Cancel
Call
OK
Store 123
Pt1
Pt2
+AZ
HD
m
VD
m
Input
Call
Meas.
OK
Save 123
N
-5.408
m
E
8.565
m
Z
0.393
m
Pt.N
3
Code
A
Cancel
Call
OK
