Ruide RCS - 10.2 Edit Horizontal Alignment Data

40
 Enter the STA, O/S and dVD
STA: the horizontal distance along the
baseline.
O/S: the horizontal distance perpendicular
to the line.
dVD:vertical distance to the baseline
 Press [OK] to calculate the coordinate
 Press [OK] to save the point
9.4.2 Calculate AZ
 Press [2] to choose calculate AZ by two points
 Enter the two points to define the base line.
 Enter the STA, O/S and dVD
STA: the horizontal distance along the
baseline.
O/S: the horizontal distance perpendicular
to the line.
dVD:vertical distance to the baseline
 Press [OK] to calculate the coordinate
Line Offset 123
STA
1.000
m
O/S
2.000
m
dVD
0.500
m
Cancel
OK
Save 123
N
-5.408
m
E
8.565
m
Z
0.393
m
Pt.N
3
Code
A
Cancel
Call
OK
Define Line
1.
Input AZ
2.
Calc AZ
Cancel
Line Offset 123
Pt1
1
Pt2
2
Input
Call
Meas.
OK
Line Offset 123
STA
1.000
m
O/S
2.000
m
dVD
0.500
m
Cancel
OK
