PROPELLER
10. STEVNFLENSSKRUE MEO MUTTER
STERN WOOO SCREW WITH NUT
Pos.: 10-11: 1/2" x 3" std. Sl-91L 2
1/2" x 4" Sl-91Lc (2)
1/2" x 5" Sl-91Ld (2)
11. Mutter, 1/2" W, metall . (491c) 441.038 2
Nut
For plast- og stAlbAter/
For GRP and steel boats:
Hode-stevnskrue M12 x 50, rustfri ... 432.108 (2)
Stern bolt, stainless steel
Underlagsskive 721.007 (4)
Washer
Mutter M12 441.068 (2)
;: Nut
0
~ 12. Stevnflens 2H91C 1
iD' Stern bearing
: 13. Vingekloss 2H91m 2
E Ving tap block
, E
0
~ 0 15. Hylser0r, 33 x 450 mm std. 891h 1
~ Stern tube 330 x 550 mm 891hd (1)
330 x 700 mm 891he (1)
,x 330 x 850 mm 891hf (1)
c 330 x 1000 mm 891hg (1)
00
~ ~ HYLSEPAKK80KS KOMPLETT Sl-2H91F8
.'; " STUFFING 80~ ASSEM8LY
IV
~ Pos.: 16-17-18-19
(Q
(Q
~ 16. Hylsepakkboks 2H91F8 1
,~ . Stuffing box
m 17. Talgpakning 1/4" x 827.014 3
~ Stuffing box gasket
...
18. Gland 891g 1
Gland
Fettkopp No. 4 (982b) 517.020 1
Grease cup
HYLSEFETTKOPP KOMPLETT (64Ab/8b) 64.001
PROPELLER GREASER CO~PLETE
Pos.:: 21-22-23
HYLSEFETTKOPP KO~PLETT ~EO R0R 64.002
PROPELLER GREASER WITH TU8E
Pos.: 21-22-23-24
.
~ 23. Overgangsforskruning R 1/4" x 1/8" 513.014 (1)
Reducing nipple
