System Operations Page 3-
Button Description
Special Function Buttons:
Standby (Home) In most instances the standby button is
used to bring the user back to the main
menu and place the Model 2010D in
standby mode to await further commands.
Sun Button The sun button is used to illuminate the
display screen or blank the display
screen. In normal mode, the button is
pressed to illuminate the display screen
and in alternate mode, pressing the button
invokes the screen saver to blank the
screen.
Status (F8) The status button is used to obtain updated
status information about the operation of
the calibrator.
Purge (!) The purge button momentarily activates the
purge valve for flushing calibrator source
manifold pneumatics.
Audit (F7) This button is used to place the calibrator
in run calibration sequence mode. If a
sequence is active, the user will be
returned to the "Select a Point" screen to
change points.
Set-up (F10) This button is used to initiate the setup
of calibration sequences.
Diag (F11) This button is normally used to activate
the diagnostics selection menu. If a
status screen is active when the Diag
button is pressed, however, it causes
Debug Mode to be selected, allowing
control values in the status screen to be
changed.
