SAGEMCOM F@ST 2804v2 User Manual

5 - Information / Configuration
F@st™ 2804v2 Reference Manual - 253329475-A
Sagemcom document. Reproduction and disclosure prohibited Page 5-41
Field Action Default
Traffic Class Name
Enter a name for the traffic class you want to
create.
Empty
Wireless Transmit Priority
In the scroll down list, select the priority you
want to allocate to the traffic class you
selected (see table below).
0 - WMM
Best Effort
(default)
Protocol
Select the appropriate protocol from the scroll
down list (TCP/UDP, TCP, UDP, ICMP).
Empty
Source IP Address
Enter a Source IP address (LAN).
Empty
Source Subnet Mask
Enter a sub-net mask associated with the
"Source" IP address.
Empty
UDP/TCP Source Port
(port or port:port)
Enter a "Source" port or range of ports.
Note: For one port, for example, enter 80.
For a range of ports, enter 80:90.
Empty
Destination IP Address
Enter a "Destination" IP address (WAN).
Empty
Destination Subnet Mask
Enter a sub-net mask associated with the
"Destination" IP address.
Empty
UDP/TCP Destination Port
(port or port:port)
Enter a "Destination" port or range of ports.
Note: For one port, for example, enter 80.
For a range of ports, enter 80:90.
Empty
Transmission priority Meaning
0 - WMM Best Effort (default)
This is the lowest priority. This provides no guarantee of
data transmission.
1 - WMM Background
2 - WMM Background
These are intermediate priorities. These provide routing
without too much data flow loss.
3 - WMM Best Effort
This priority provides no guarantee of data transmission.
4 - WMM Video priority
5 - WMM Video priority
These are intermediate priorities. They provide a correct
routing for "Video".
6 - WMM Voice priority
7 - WMM Voice priority
These are higher priorities. They provide complete routing
for voice
Click on the
button to save the parameters.
