5 - Information / Configuration
F@st™ 2804v2 Reference Manual - 253329475-A
Page 5-56 Sagemcom document. Reproduction and disclosure prohibited
PPP over Ethernet (PPPoE)
Field Action Default
Encapsulation Mode
Select the encapsulation of your choice from the
scroll down list.
• LLC/SNAP-BRIDGING,
• VC/MUX.
LLC/SNAP-
BRIDGING
MAC Encapsulation Routing (MER)
Field Action Default
Encapsulation Mode
Select the encapsulation of your choice from the
scroll down list.
• LLC/SNAP-BRIDGING,
• VC/MUX.
LLC/SNAP-
BRIDGING
IP over ATM (IPoA)
Field Action Default
Encapsulation Mode
Select the encapsulation of your choice from the
scroll down list.
• LLC/SNAP-ROUTING,
• VC/MUX.
LLC/SNAP-
ROUTING
Bridging
Field Action Default
Encapsulation Mode
Select the encapsulation of your choice from the
scroll down list.
• LLC/SNAP-BRIDGING,
• VC/MUX.
LLC/SNAP-
BRIDGING
PPPoE/PPPoA
The encapsulation mode field will be selected automatically with PPPoE/PPPoA
protocol type.
