SAM300 Reference Manual v1.0 Introduction 5
Requirements
To use this utility, you must have:
Pentium 100 or faster CPU.
32 MB RAM.
150 MB minimum hard disk space available.
Dedicated serial port (RS-232C).
CD ROM drive.
VGA or SVGA display.
Windows XP or above operating system.
Screen resolution of 800 x 600 pixels.
US Robotics V.92 56K External Modems are recommended for remote connection by
modem (for both PC and ECR sites) or Internet connection for IP polling.
Installing
Notes:
SAM Polling software requires a USB software key to be installed on the PC running the
software to access all of the polling and programming features. Software can be installed on a
PC without the key, but it can be used only for program saving/loading.
The connection from the ECR to your PC requires a serial port on the PC. See “Cabling
Diagrams” on page 78 for more information on cables and connections.
1. Load the SAM300 program CD into your CD drive (or load via SD/USB memory device).
2. From the Windows Desktop, double click the My Computer icon.
3. Select your CD ROM drive (usually drive "D".)
4. Choose Setup. The Welcome dialog displays.
5. Click Next. The Ready to Install dialog displays.
6. Click Next. The Install Directory dialog displays.
7. Click Next. The Select Shortcut Folder dialog displays.
8. Click Next. When all files are copied, the Finished dialog displays.
9. Click Finish.
10. Next, the HSAP SRM loads the driver for the software key.
11. When the driver installation is complete, the HASP SRM dialog displays.
12. Click OK.
13. Remove the CD ROM. Your installation is complete.
