78 Appendices SAM300 Reference Manual v1.0
Cabling Diagrams
Typical SAM ECR to PC Connections
Note: If you are connecting the ECR to a PC or Laptop that has no serial port, you must use a USB to Serial
adaptor as shown above. CRS offers a USB to Serial adaptor from Perle that has been tested and is known to
work with SAM polling software products.
Posio USB to
Serial Adaptor
Serial Com Cable
(see below)
DB-9M DB-9F
Serial Com Cable
(see below
DB-9M
SAM4s
ECR
SAM4s
ECR
DB-9F
