Annex A (conguration instructions)
− Adopt binary input's state (c15 = BIN): The binary output reproduces the logical state of
the binary input.
− Indicate manual mode (c15 = MAN): The binary output is active when the manual mode
(MAN) is active (Code 2) or the manual level in TROVIS-VIEW is active.
Code Description Default Adjustment range
c15 Function NONE NONE (inactive)
FAIL (error indication)
LIM (limit contact)
PRIO (priority position)
BIN(adoptbinaryinput)
MAN (indicate manual mode)
c16 Switching state for active function NINV NINV (not inverted)
INV (inverted)
When c15 = LIM
c21 Electronic limit contact (binary output)
Message in case of event
NONE NONE (inactive)
HIGH(valueabovelimit)
LOW (value below limit)
c22 Switching point of limit contact (binary
output)
10.0% 0.0to100.0%
c23 Hysteresisofelectroniclimitcontact(bi-
nary output)
1.0% 0.0to10.0%
16.8 Electronic limit contacts
The electronic limit contact can be triggered by the actuator stem position exceeding or fall-
ing below an adjustable switching point.
− Triggered when the position exceeds the switching point: The limit contact is activated
when the actuator stem position moves beyond the switching point. The limit contact is
deactivated when the actuator stem moves below the switching point plus hysteresis.
− Triggered when the position moves below the switching point: The limit contact is acti-
vated when the actuator stem position moves below the switching point. The limit contact
is deactivated when the actuator stem position moves beyond the switching point plus
hysteresis.
