Samson 3374 Series User Manual

EB 8331-4 EN 4-1
Shipment and on-site transport
4 Shipment and on-site trans-
port
The work described in this section is only to
be performed by personnel appropriately
qualiedtocarryoutsuchtasks.
4.1 Accepting the delivered
goods
After receiving the shipment, proceed as fol-
lows:
1. Compare the shipment received with the
delivery note.
2. Check the shipment for transportation
damage. Report any damage to
SAMSON and the forwarding agent
(refer to delivery note).
4.2 Removing the packaging
from the actuator
Do not remove the packaging until immedi-
ately before mounting and start-up.
1. Remove the packaging from the electric
actuator.
2. Checkscopeofdelivery(seeFig.4-1).
3. Dispose of the packaging in accordance
with the valid regulations.
Note
1x Type3374-xxElectricActuator
1x DocumentIP8331-4
(Important Product Information)
forTypes3374-10,-11,-21,-31:
1x Accessory 1400-6817, consisting of
2x Stem connector for
Ø10mmstem
2x M5 hex bolt
2x M5 hex nut
forTypes3374-15,-26,-36:
1x Accessory 0900-2679, consisting of
2x Stem connector for
Ø16mmstem
2x M6 screw
1x M30x1.5 ring nut
Fig.4-1: Scope of delivery
4.3 Transporting the actuator
− Protect the actuator against external in-
uences(e.g.impact).
− Protect the actuator against moisture and
dirt.
− Observe the permissible transportation
temperatureof–20to+70°C.
4.4 Lifting the actuator
Due to the low service weight, lifting equip-
ment is not required to lift the electric actua-
tor.
