Samson 3374 Series User Manual

7-4 EB 8331-4 EN
Start-up and conguration
7.2.1 Fast conguration level
Code8opensthefastcongurationlevel,whichallowstheselectionofseveralparameter
congurations.
Code Description Display Adjustment range
8 Fastconguration FCO In, Out, dir (see table below)
The settings for the following areas can be selected:
− Input signal (Code In)
− Position feedback signal (Code Out)
− Operating direction (Code dir)
Code Description Display
In
Inputsignal0to20mA 0–20
Inputsignal4to20mA 4–20
Inputsignal0to10V 0–10
Inputsignal2to10V 2–10
Out
Positionfeedbacksignal0to20mA 0–20
Positionfeedbacksignal4to20mA 4–20
Positionfeedbacksignal0to10V 0–10
Positionfeedbacksignal2to10V 2–10
dir
Operatingdirectionincreasing/increasing >>
Directionofaction:increasing/decreasing <>
Only one setting can be selected for each range. Selected settings are marked on the display
by dashes (see next page).
Open fast conguration level
1. Turn
(when the start screen appears) to select Code 8 (dis-
play: FCO).
2. Press . First setting that can be selected appears.
Note
