Operation
8.4.1 Zero calibration
Risk of injury due to the actuator stem extending or retracting.
Î Do not touch or block the actuator stem.
The process is disturbed by the movement of the actuator stem.
Î Do not perform the zero calibration while the process is running. First isolate the plant by
closing the shut-off valves.
Theactuatorstemmovestothe0%endposition.Followingthis,theactuatorchangesto
closed-loopoperationandmovestheactuatorstemtothepositiondenedbytheinputsig-
nal.
Code Description Adjustment range
d51 Start zero calibration ZER
Î Zero calibration can be canceled at all times by selecting ESC.
8.4.2 Initializing the actuator
Risk of injury due to the actuator stem extending or retracting.
Î Do not touch or block the actuator stem.
The process is disturbed by the movement of the actuator stem.
Î Do not perform the initialization while the process is running. First isolate the plant by
closing the shut-off valves.
Î Theprocedureisdescribedinthe'Start-upandconguration'section.
Code Description WE Adjustment range
d52 Start initialization INI
WARNING
!
NOTICE
!
WARNING
!
NOTICE
!
