3-10 EB 8331-4 EN
Design and principle of operation
3.6 Dimensions in mm
Type3374-10/-11/-21/-31
1)
When the actuator stem is fully extended
Type 3374 Dimension h
-10 30
-11 15
-21 15
-31 15
57
194
50
1)
h
298
120
120
h
1
1)
220
h
57
193
146
146
10
16
Fig.3-5: Dimensions (in mm) of Type3374, construction with integrated yoke (formB)
