EB 8331-4 EN 3-11
Design and principle of operation
Types3374-15/-26/-36
1)
When the actuator stem is fully extended
Type 3374 Dimension h Dimension h
1
-15 30 90
-26 15 75
-36 15 75
57
194
50
1)
h
298
120
120
h
1
1)
220
h
57
193
146
146
10
16
Fig.3-6: Dimensions (in mm) of Type3374, construction with ring nut (form A)
