Samson 3374 Series User Manual

EB 8331-4 EN 12-1
Removal
12 Removal
The work described in this section is only to
be performed by personnel appropriately
qualiedtocarryoutsuchtasks.
Risk of fatal injury due to electric shock.
Î Before disconnecting live wires, switch
off the supply voltage at the actuator and
protect it against unintentional reconnec-
tion.
12.1 Construction with inte-
grated yoke
Actuator without fail-safe action
1. Disconnect the supply voltage and pro-
tect it against unintentional reconnection.
2. Make sure that a signal from the control-
ler cannot act upon the actuator. If neces-
sary, disconnect the wires connecting the
controller.
3. Disconnect the wires of the connecting
lines at the actuator.
4. Remove the connecting lines.
5. Retract the actuator stem as described in
the 'Operation' section.
6. Undo the stem connector parts between
the plug and actuator stems.
7. Loosen the nut at the yoke.
8. Lift the actuator off the valve.
Actuator with "stem extends" fail-safe
action
1. Retract the actuator stem as described in
the 'Operation' section.
2. Undo the stem connector parts between
the plug and actuator stems.
3. Loosen the nut at the yoke.
4. Make sure that a signal from the control-
ler cannot act upon the actuator. If neces-
sary, disconnect the wires connecting the
controller.
Î The actuator stem moves to the fail-safe
position.
5. Disconnect the supply voltage and pro-
tect it against unintentional reconnection.
6. Disconnect the wires of the connecting
lines.
7. Remove the connecting lines.
8. Lift the actuator off the valve.
Actuator with "stem retracts" fail-safe
action
1. Disconnect the supply voltage and pro-
tect it against unintentional reconnection.
Î The actuator stem moves to the fail-safe
position.
2. Make sure that a signal from the control-
ler cannot act upon the actuator. If neces-
sary, disconnect the wires connecting the
controller.
3. Disconnect the wires of the connecting
lines at the actuator.
4. Remove the connecting lines.
5. Undo the stem connector parts between
the plug and actuator stems.
DANGER
!
