Samson 3374 Series User Manual

16-16 EB 8331-4 EN
Annex A (conguration instructions)
16.14 Levels and parameters
16.14.1 Information level
Code Parameters (read only) Reading/unit Section
Input signal
i01 Lower range value of input signal V or mA
1)
Start-upandconguration
i02 Upper range value of input signal V or mA
1)
i03 Positioning value %/state
i04 Unit V or mA
1)
Control
i05 Valve position %/°C/bar/withoutunit
Design and principle of
operation
i06 Set point %/°C/bar/withoutunit
i07 Error signal %
i08 Active controller State
i09 Positioning value %
Travel
i11 Actuator travel %
Start-upandconguration
i12 Actuator travel mm
Position feedback signal
i21 Lower range value of position feedback signal V or mA
1)
Start-upandconguration
i22 Upper range value of position feedback signal V or mA
1)
i23 Position feedback signal %
i24 Position feedback signal V or mA
1)
Binary signals
i31 Binaryinputstatus ON/OFF
Start-upandconguration
i32 Binaryoutputstatus ON/OFF
Limit contact
i41 Status of limit switch (stem retracted) ON/OFF
Start-upandconguration
i42 Status of limit switch (stem extended) ON/OFF
