Samson 3374 Series - Page 105

EB 8331-4 EN 16-13
Annex A (conguration instructions)
− User-dened (c71 = USER, c72= USE): A new characteristic based on the last char-
acteristicusedcanbedenedoverelevenpoints.
Code Description Default Adjustment range
c71 Characteristic type LIN LIN (linear)
EQUA (equal percentage)
INV (reverse equal percentage)
USER(user-dened)
When c71 = USER
c72 = USE User-denedcharacteristic
H0,Y0 Input value X0, output value Y0 0.0% 0.0to100.0%
H1,Y1 Input value X1, output value Y1 10.0% 0.0to100.0%
H2,Y2 Input value X2, output value Y2 20.0% 0.0to100.0%
H3,Y3 Input value X3, output value Y3 30.0% 0.0to100.0%
H4,Y4 Input value X4, output value Y4 40.0% 0.0to100.0%
H5,Y5 Input value X5, output value Y5 50.0% 0.0to100.0%
H6,Y6 Input value X6, output value Y6 60.0% 0.0to100.0%
H7,Y7 Input value X7, output value Y7 70.0% 0.0to100.0%
H8,Y8 Input value X8, output value Y8 80.0% 0.0to100.0%
H9,Y9 Input value X9, output value Y9 90.0% 0.0to100.0%
H10,Y10 Input value X10, output value Y10 100.0% 0.0to100.0%
