Samson 3374 Series User Manual

EB 8331-4 EN 16-31
Annex A (conguration instructions)
HR Designation Access
Transmission range Reading range
Start End Start End
Operating values (outputs)
18 Travelin% R 0 1000 0 100.0
19 Travel in mm R 0 1000 0 100
20 Setpointdeviationofpositionerin%(positioning
value/travel)
R –1000 1000 0 100
21 SetpointdeviationofPIDcontrollerin%(setpoint/
process variable)
R –1000 1000 0 100
Operating values (position feedback)
22 Positionfeedbackin% R 0 1000 0 100.0
23 PositionfeedbackinmA/V R 0 240 0 24.0
24 Unit of position feedback R 0 1 0 1
Manual level of control station
25 Manual positioning value in manual level (control
station)in%
R/W 0 1000 0 100.0
26 Set point deviation of manual level (control station)
in%
R –1000 1000 –100.0 100.0
Process data
27 Positioningvalue(manuallevelonsite)in% R 0 1000 0 100.0
28 Status of positioning value R
Binary operating data
CL Designation COILS (1-bit) Access Status 0 Status 1
Operating states
1 Errors R No Yes
2 Maintenance demanded R No Yes
3 Manual level on site active R No Yes
4 Enable manual level of control station (travel adjustment) R/W*H No Yes
Binaryinput
5 Binaryinputstatus R Off On
6 Binaryinput(switchingcontact) R Off On
Limits
7 State of electronic limit contact 1 R Off On
8 State of electronic limit contact 2 R Off On
9 Electronic limit contacts exist R Off On
