Samson 3374 Series - Page 38

5-10 EB 8331-4 EN
Installation
The function of the inputs depend on how the actuator is congured: inputs that have not
been congured do not have any effect.
Table 5-1: Cables and stranded wires that can be used
Cable Cross section
Single-wireH05(07)V-U
1)
0.2to1.5mm²
Fine-wireH05(07)V-K
1)
0.2to1.5mm²
Withwireferruleacc.toDIN46228-1 0.25to1.5mm²
Withwireferruleandsleeveacc.toDIN46228-4 0.25to0.75mm²
1)
Lengthofinsulationtobestrippedoffwireends=8mm
Note
