10.3 Programming Example
Figure 10.2 below shows the example of the networking programming that uses both of the
PRI networking and the VoIP networking, and is configured only with OfficeServ 100
systems.
Figure 10.2 Networking Programming Example for Each Point
trunk
System A
Node ID
Station No.
trunk line Group
PRI Network group
VoIP Network group
SVMi Group No.
A
ttendant No.
091
2000~2099
800
801, 802
803
5049
5000
System B
Node ID
Station No.
trunk line Group
PRI Network group
VoIP Network group
SVMi Group No.
A
ttendant No.
092
2100~2399
None
800
803
None
None
System C
Node ID
Station No.
trunk line Group
PRI Network group
VoIP Network group
SVMi Group No.
A
ttendant No.
093
2400~2599
None
800
None
None
None
System D
Node ID
Station No.
trunk line Group
PRI Network group
VoIP Network group
SVMi Group No.
A
ttendant No.
094
2600~2699
None
None
803
None
None
800
801 PRI 800
802
800
PRI
803
VoIP
803
VoIP
803
VoIP
Internet
