CHAPTER 2. Installing Basic KSU and Expansion Cabinet
2-12
© SAMSUNG Electronics Co., Ltd.
2.8.3 Recommended Battery Specification
Table 2.2 Recommended Battery Specification
Current Charge Discharge
Minimum Load Current(A) 0 0.05
Maximum Load Current(A) 0.4 0.7
Normal Load Current(A) 0.1 0.5
Normal Output Voltage(V) 54 49
Max KTS current consumption: 30 mA
When installing appropriate batteries
Be sure the polarity is observed. Equipment damage will result if polarity is reversed.
Do not connect external AC/DC power to the OfficeServ 100 system if the system
is damaged by electrical power.
