OfficeServ 100 Installation Manual/Ed.00
© SAMSUNG Electronics Co., Ltd. 2-5
2.4 Expansion KSU Installation
Expansion KSU is simply attached to basic KSU with the following procedure.
This manual instanced the Expansion cabinet A as the installation figures. The installation
procedure of Expansion Cabinet A is same with Expansion Cabinet B.
Figure 2.2 Basic KSU + Expansion A
Figure 2.3 Basic KSU + Expansion B
