3.19 MGI3 Card (only use in the OfficeServ 100)
The MGI3 card supports the VoIP Gateway, which enables telephone calls through the
Internet. Since the MGI3 card cannot support the H.323 protocol by itself, the MGI3 card
shall always be used together with the MCP1 card.
When mounted with the 500 MGI3 D-board, the MGI3 card can support up to 16 Internet
telephone(VoIP) ports by adding 8 channels of Internet telephone ports. Up to 3 cards
MGI3 shall be installed in the Basic cabinet 3 universal slot.
Push firmly in the middle of both card ejectors to ensure the card is firmly seated into the
back plane connector
The features of the MGI3 card(such as LAN port connection, RS232C connection, Reset
button, and jumper setting) are identical to that of the ITM3 card, except for the front panel
LED feature.
Table 3.4 LED Display of the MGI3 Card
LED Color Description
PWR Light Green Displays the power supply status of the MGI3 board.
- On: Power is supplied normally.
- Off: No power supply.
SRV Light Green Displays if the voice service is available.
- Blink: Service is available.
- Off: Service is unavailable.
Tx Light Green Displays the status of data transmission through Ethernet.
- Blink: Data is being transmitted.
- Off: No data transmission.
Rx Light Green Displays the status of data reception through Ethernet.
- Blink: Data is being received.
- Off: No data reception.
RUN Light Green Displays the operation status of the MGI3 card.
- On: MGI3 card is operating normally.
- Off: MGI3 card is not operating normally.
IPC Light Green Displays if messages are transferred between MGI3 card and the main
control part.
- Blink: Messages are transferred normally.
- Off: No message transfer.
DSP Light Green Displays the usage rate of the DSP channel.
- Blink: DSP channel is being used. Blinks every 1 second for 1 to 4
channels, 0.5 second for 5 to 8 channels, 0.25 second for 9 to 12
channels, and 0.125 second for 13 to 15 channels.
- On: All 16 channels are being used.
- Off: No DSP channel in use.
