CHAPTER 2. Installing Basic KSU and
Expansion Cabinet
This chapter describes how to install the OfficeServ 100 KSU and expansion cabinet.
2.1 System Capacity
OfficeServ 100 system can have up to 48 stations if SVMi-8 is not used, and can have up to
40 stations if SVMi-8 is used. There is no limit in the analog C.O. line, and ISDN C.O line
if any slot is available and PRI(TEPRI) or SVMi-8 can be adopted in the DCS slot on the
EXP cabinet of OfficeServ 100. Some configuration examples are below.
 In this table, 4BRI(4S0T0) is used as digital trunk.
 4BRI(4S0T0) card can be used as ISDN NT. Each port can have up to 8 ISDN TEs,
but power consumption of each port is limited to 4 WATT.
 Only one ITM3 card can be equipped into the basic cabinet slots per system.
Table 2.1 System Capacity
Combination of Boards
Loop Start
Trunk/BRI I/F
Key sets
KDB-D
/KDB-S
Max Capacity
(Including KDB line)
Basic 0 8 8 0 * 8(16)
Basic + 3TRK
3 8 8 3 * 8(16)
Basic + 4BRI(4S0T0)
4(8CH) 8 8 8 * 8(16)
Basic + 4BRI(4S0T0) + 8DLI * 2
4(8CH) 24 8 8 * 24(32)
Basic + 3TRK * 2 + 8DLI
6 16 8 6 * 16(24)
Basic(4BRI(4S0T0) + 8DLI * 2)
+ EXP(4BRI(4S0T0) + 8DLI * 2)
8(16CH) 40 8 16 * 40(48)
Basic(6TRK + 8DLI* 2) + EXP
(3TRK *2 + 8DLI)
12 32 8 12 * 32(40)
Basic KSU
Basic KSU Plus
Ex
p
ansion KSU
