Samsung OfficeServ 100 - Figure 3.17 LED Display of the MGI3 Card; Figure 3.18 MGI3 Card

OfficeServ 100 Installation Manual/Ed.00
© SAMSUNG Electronics Co., Ltd. 3-19
LED Color Description
MOD Light Green Displays if RTP data is incoming through LAN.
- Blink: RTP data is received normally.
- Off: No RTP data is being received.
Figure 3.17 LED Display of the MGI3 Card
Figure 3.18 MGI3 Card
PWR
SRV
Tx
Rx
RUN
IPC
DSP
MOD
