Sanyo PLC-XP200L Service Manual

Key No. Part No. Description Key No. Part No. Description
KR7-XP200L00
Electrical Parts List
-124-
D7863 307 163 0414 DIODE 1SS352-(TPH3)
D7866 307 225 0215 DIODE RB751S-40
D7867 307 163 0414 DIODE 1SS352-(TPH3)
D7891 307 163 0414 DIODE 1SS352-(TPH3)
D7892 307 163 0414 DIODE 1SS352-(TPH3)
D7922 307 163 0414 DIODE 1SS352-(TPH3)
D7923 307 163 0414 DIODE 1SS352-(TPH3)
D8031 307 163 0414 DIODE 1SS352-(TPH3)
D8032 307 210 5416 DIODE RB551V-30-TE-17
D8041 307 201 2724 DIODE RB051L-40-TE25
D8042 307 201 2724 DIODE RB051L-40-TE25
D8043 307 201 2724 DIODE RB051L-40-TE25
D851 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D852 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D853 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D854 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D855 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D856 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D857 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D9802 307 254 2716 DIODE CMS16
D9803 307 163 0414 DIODE 1SS352-(TPH3)
MISCELLANEOUS
IC1828 307 236 0310 SENSOR MPXHZ6115A6T1
SW301 945 026 2792 SWITCH,PUSH 1P-1TX1
SW302 945 026 2792 SWITCH,PUSH 1P-1TX1
X1351 945 088 7179 OSC,CRYSTAL 27.0MHZ
X2201 945 076 2407 OSC,CRYSTAL 25.000MHZ
X2331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X301 945 087 8856 OSC,CRYSTAL 28.322MHZ
X4801 645 092 8857 OSC,CRYSTAL 48MHZ
X5201 945 076 5194 OSC,CRYSTAL 79.991883MHZ
610 339 9690 ASSY,PWB,CONTROL KR7AL
CAPACITOR
C6878 303 409 3426 CERAMIC 0.1U K 16V
RESISTOR
R6871 301 225 1814 MT-GLAZE 47 JA 1/16W
R6872 301 225 1814 MT-GLAZE 47 JA 1/16W
R6873 301 225 1814 MT-GLAZE 47 JA 1/16W
R6874 301 225 1814 MT-GLAZE 47 JA 1/16W
R6875 301 225 1814 MT-GLAZE 47 JA 1/16W
R6876 301 225 1814 MT-GLAZE 47 JA 1/16W
R6878 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
DIODE
D6871 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6872 307 163 0414 DIODE 1SS352-(TPH3)
D6873 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6874 307 163 0414 DIODE 1SS352-(TPH3)
D6875 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6876 307 163 0414 DIODE 1SS352-(TPH3)
D6877 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6878 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6879 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6880 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
D6895 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
MISCELLANEOUS
SW6871 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6872 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6873 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6874 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6875 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6876 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6877 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6878 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6879 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6880 945 026 2792 SWITCH,PUSH 1P-1TX1
610 339 9706 ASSY,PWB,SENSOR KR7AL
CAPACITOR
C1801 303 409 3426 CERAMIC 0.1U K 16V
RESISTOR
R1898 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R1899 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
610 339 9638 ASSY,PWB,A/V KR7AL
TRANSISTOR
Q1001 305 217 4913 TR RN1111 TE85L
Q1002 305 217 4913 TR RN1111 TE85L
Q1003 305 217 4913 TR RN1111 TE85L
Q1004 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1008 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1009 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1011 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1012 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1014 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1016 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
