Sanyo PLC-XP200L Service Manual

-47-
Electrical Adjustment
Service Adjustment Data Table
These initial values are the reference data written from the
CPU ROM to memory IC when replaced new memory IC. The
adjustment items indicated with “✻” are required to readjust fol-
lowing to the “Electrical adjustments”. Other items should be
used with the initial data value.
Grp / No. Item Function Range Initial Note
0 AD Converter (PW392)
3 ADC G-GAIN
YCbCr 480i (575i) / YCbCr 480p (575p) / YCbCr 720p (720p50) /
YCbCr 1080i (1035i, 1080i50) / SCART
0 - 1023 210/210/ 212/212/229
4 ADC R-GAIN
YCbCr 480i (575i) / YCbCr 480p (575p) / YCbCr 720p (720p50) /
YCbCr 1080i (1035i, 1080i50) / SCART
0 - 1023 235/235/ 235/235/232
5 ADC B-GAIN
YCbCr 480i (575i) / YCbCr 480p (575p) / YCbCr 720p (720p50) /
YCbCr 1080i (1035i, 1080i50) / SCART
0 - 1023 225/225/ 225/225/233
10 SOGTH COMPONENT / SCART 0 - 15 4 / 4
11 SOGHYSDIS COMPONENT / SCART 0 - 1 1 / 0
12 HS1TH H Sync1 Threshold COMPONENT / SCART 0 - 7 4 / 4
13 HS0TH H Sync0 Threshold COMPONENT / SCART 0 - 7 4 / 4
10 AD Converter (ISL51002/ISL98001)
3 ADC G-GAIN PC 0 - 1023 235
4 ADC R-GAIN PC 0 - 1023 235
5 ADC B-GAIN PC 0 - 1023 235
20 Video Decoder
0 Y Level
Composite 60Hz/ S-Video 60Hz/ Composite 50Hz / S-Video
50Hz- Y Level (ADC RGB Gain)
0 - 1023 153/153/161/161
1 C Level
Composite 60Hz / S-Video 60Hz / Composite 50Hz / S-Video
50Hz - C Level (ADC Saturation)
0 - 1023 410/410/440/440
10 XCXL Parameter XCXL Level 0 - 4 2
11 Sync Amp Low Minimum sync amplitude threshold for HLOCK 1 to 0 transition 0 - 9999 1792
12 Sync Amp High Minimum sync amplitude threshold for HLOCK 0 to 1 transition 0 - 9999 4096
13 Luma Setup Enable 7.5IRE Mode (NTSC only) 0 - 1 0
14 Anti-Alias Filter Anti-Alias Filter 0 - 7 4
15 Anti-Alias Downsample Anti-Alias Downsample 0 - 3 0
16 Anti-Alias High Frequency Anti-Alias High Frequency 0 - 3 3
20
Comb 3D Cross-Luma Top/Bottom
Amplitude
for PAL/SECAM only 0 - 3 3
40 General
0 IP Mode Set at IP OFF ０: Not used IP Block 1: Used IP Block and IP OFF 0 - 1 1
1 3:2 PullDown Mode bit0: Global Motion bit1: Video Motion 1 - 3 1
2 Detect Film Mode Enable 0: 2:3pull down & 2:2pull down 1: 2:3pull down 2: 2:2pull down 0 - 2 0
3 NR Enable for Analog YUV
0 : Noise Reduction detected with Y and UV motion 1 : Noise
Reduction detected with Y motion
0 - 1 1
4 NR Enable for Digital YUV 0 - 1 0
41 Deinterlacer setting Progressive Mode1, Film Parameter
0 Motion Adaptive Weight Value <KDEINT> 0 - 255 25/25/25
1 Angle Interpolation Level 0 : Conservative <= == => 4 : Aggressive 0 - 4 2/2/2
2 CUE Low Pass Filter Enable <CUELPFEN> 0 - 1 0/0/0
42 Deinterlacer setting Progressive Mode2 Parameter
0 Motion Adaptive Weight Value <KDEINT> 0 - 255 0/0 /0
1 Angle Interpolation Level 0 : Conservative <= == => 4 : Aggressive 0 - 4 2/2/2
2 CUE Low Pass Filter Enable <CUELPFEN> 0 - 1 0/0/0
47 Noise Reduction (time) NR L1 Parameter
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 0 - 2 1
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 0 - 1023 12
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 0 - 1023 24
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 0 - 1023 40
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 0 - 255 100
49 Noise Reduction (time)
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 0 - 2 1
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 0 - 1023 12
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 0 - 1023 24
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 0 - 1023 40
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 0 - 255 100

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
