Mechanical Parts List

KR7-XP200L00

CABINET PARTS

C01 610 335 5092 COMPL,STAND LEG-KC3BL

C02 610 340 4158 BUTTON CONT-KR7AL

C03 610 340 6947 CABINET TOP-KR7AL

C04 610 334 1347 CABINET FRONT-KC3A

C05 610 334 1422 CABINET FRONT COVER F-KC3A

C06 610 340 6954 CABINET FRONT COVER T-KR7AL

C07 610 340 4141 CABINET BACK-KR7AL

C08 610 340 7166 CABINET BOTTOM-KR7AL

C09 610 340 6992 COVER FUSE-KR7AL

C10 610 340 6961 COVER HANDLE-KR7AL

C11 610 334 2054 COVER NON LENS-KC3AL

C12 610 334 3303 DEC INLAY LED-KC3A

C13 910 302 5613 DEC SHEET-M4JA

C14 610 340 4967 DEC AV SHEET-KR7AL

C15 610 334 2139 HOLDER STOPPER-KC3A

C16 610 340 6978 PANEL LMP-KR7AL

C17 610 340 6985 PANEL FILTER-KR7AL

C18 910 293 9973 SPACER LEG-MA8A

C19 910 298 8575 SPACER COVER NWMG-MA8BA

C20 910 298 8582 SPACER COVER SCREW NWMG-MA8BA

C21 610 334 2023 SPRING STOPPER-KC3A

C22 610 341 1903 STOPPER COVER TOP-KR7AL

CHASSIS PARTS

M01 610 334 3747 ASSY,BOX FILTER-KC3A

M02 610 334 3501 COMPL,HOLDER LNS SHIFT-KC3A

(Inlcuding Key No. M02-1 to M02-4)

M02-1 910 306 6630 ASSY,PWB,LENS-BASE NET MR3A

M02-2 610 334 3891 ASSY,HOLDER MTR LNS-KC3A

M02-3 645 092 6600 UNIT,LENS,SHIFT-X

M02-4 645 092 6617 UNIT,LENS,SHIFT-Y

M03 610 334 3549 GEAR MOTOR-KC3A

M04 610 334 3112 HOLDER FILTER BASE-KC3A

M05 610 336 9921 COMP,HOLDER SHAFT FILTER-KC3A

M06 910 313 6678 LATCH-P8FK

M07 610 334 4300 MTG HLD SHAFT FIL-KC3A

M08 610 340 5469 COMPL,MOUNTING SHUTTER-KR7AL

M09 610 334 3051 HOLDER POL IN A-KC3A

M10 610 334 2849 HOLDER FILTER COVER-KC3A

M11 610 334 2771 HOLDER FILTER-KC3A

M12 610 341 1484 HOLDER POL IN A-KR7AL

M13 610 340 4936 MTG DUCT TOP LCD-KR7AL

M14 610 340 4929 MTG DUCT BTM LMP-KR7AL

M15 610 340 4943 MTG DUCT TOP LMP-KR7AL

M16 610 340 4950 MTG DUCT PBS-KR7AL

M17 610 340 9733 MTG DUCT BTM LCD-KR7AL

M18 610 341 1637 OPTICAL BASE TOP-KR7AL

M19 610 334 1484 OPTICAL LMP COVER UV-KC3A

M20 610 341 4935 ASSY,COVER YE-KR7AL

SCREWS

S01 411 189 8600 SCR BIN 3X8

S02 312 069 8300 SPECIAL SCREW W

S03 411 189 7207 SCR S-TPG BIN 3X8

S04 411 189 6606 BOLT HEX-SCT 2.5X6

S05 312 074 7107 SPECIAL SCREW V

OPTICAL PARTS

L01 610 341 1996 COMPL,OPTICAL-KR7AL

(Inckuding Key No. L01-1 to L01-13 and L02)

L01-1 945 041 3712 ASSY,PRISM(PBS)

945 051 9421 ASSY,PRISM(PBS)

L01-2 945 047 2856 LENS,CONDENSER(IN)

L01-3 945 047 2870 LENS,CONDENSER(R)

L01-4 945 047 2887 LENS,RELAY(IN)

L01-5 945 085 7844 LENS,CONDENSER (B)

L01-6 645 097 3109 LENS,CONDENSER (G)

L01-7 945 044 2576 MIRROR(R)

L01-8 945 047 7516 MIRROR(B)

L01-9 945 086 2992 MIRROR(W-COLD)

L01-10 645 097 1808 OPTICAL FILTER(LC-CS)

L01-11B 645 093 0027 POLARIZED GLASS(IN/GB)

L01-11G 645 093 0027 POLARIZED GLASS(IN/GB)

L01-12 945 047 2924 DICHROIC MIRROR (B)

L01-13 645 098 9360 DICHROIC MIRROR (G)

Type-L LCD Panel/Prism Ass'y

L02L 610 341 2962 ASSY,PNL/PSM L-KR7AL

(Includng Key No. L02L-1, L02L-2 and LCD Panels)

L02L-1R 645 098 1746 POLARIZED GLASS(OUT/R)

L02L-1G 645 098 1753 POLARIZED GLASS(OUT/G)

L02L-1B 645 098 1760 POLARIZED GLASS(OUT/B)

L02L-2R 645 093 0010 PREPOLARIZED GLASS(R)

L02L-2G 645 093 0546 PREPOLARIZED GLASS(G)

L02L-2B 645 093 0560 PREPOLARIZED GLASS(B)

L03L-R 645 092 7355 OPTICAL FILTER (HCP)R

L03L-G 645 092 7362 OPTICAL FILTER (HCP)L

L03L-B 645 092 7355 OPTICAL FILTER (HCP)R

Type-R LCD Panel/Prism Ass'y

L02R 610 341 2979 ASSY,PNL/PSM R-KR7AL

(Includng Key No. L02R-1, L02R-2 and LCD Panels)

L02R-1R 645 098 1746 POLARIZED GLASS(OUT/R)

L02R-1G 645 098 1753 POLARIZED GLASS(OUT/G)

L02R-1B 645 098 1760 POLARIZED GLASS(OUT/B)

L02R-2R 645 093 0010 PREPOLARIZED GLASS(R)

L02R-2G 645 093 0546 PREPOLARIZED GLASS(G)

L02R-2B 645 093 0560 PREPOLARIZED GLASS(B)

L03R-R 645 092 7362 OPTICAL FILTER (HCP)L

L03R-G 645 092 7355 OPTICAL FILTER (HCP)R

L03R-B 645 092 7362 OPTICAL FILTER (HCP)L

Common

L04-R 645 098 1739 POLARIZED GLASS(IN/R)

L04-G 645 093 0034 POLARIZED GLASS(IN/G)

L04-B 645 093 0041 POLARIZED GLASS(IN/B)

* There are 2 types (Type-L or Type-R) of LCD Panel/Prism Ass’y. Used

type is indicated on the Prism Ass’y and Optical unit top. Refer to item

“LCD Panel/Prism Ass’y Removal” for further information.

Key No. Part No. Description

Mechanical Parts List

Note: Parts order must contain Chassis No., Part No., and Descriptions.
