Sanyo PLC-XP200L Service Manual

-77-
Chassis Description
Detection of Power failure
Projector provides a protection circuit to prevent the secondary failure when the power failure, fans failure or tempera-
ture failure occurs on the projector. The power failure detection lines "PF_3.3V_AD", "PF_15V_LNS", etc. are con-
nected to the main power supplies and fans. When the failure occurs, IC301<SCALER> receives an error information
through IC5201<FPGA>, IC4801 <I/O Expander> and then outputs the signal "PFC_SW_EX" from pin 32. The signal
"PFC_SW_EX" is supplied to power supply circuit as the signal "PFC_SW" via IC1871 <Buffer> to control the power
supply operation.
Error information table
Power failure detection system
IC Pin Signal Name Connection Lines Error Information Failure Area
IC5201
FPGA
59 PF_3.3V_DVI 3.3V_DVI DVI, 3.3V DVI Equalizer, IC8001
112
PF_3.3V_AD 3.3V_AD AD, 3.3V A/D, IC2201
58 PF_1.8V_AD 1.8V_AD AD, 1.8V A/D, IC2201
156 PF_3.3V_KS 3.3V_KS KS, 3.3V Keystone, IC2301
157 PF_2.5V_KS 2.5V_KS KS, 2.5V Keystone, IC2301
57 PF_1.8V_KS 1.8V_KS KS, 1.8V Keystone, IC2301
56 PF_3.3V_PIC 3.3V_PIC FPGA, 3.3V PIC FPGA, IC4401
191 PF_2.5V_PIC 2.5V_PIC FPGA, 2.5V PIC FPGA, IC4401
55 PF_1.2V_PIC 1.2.V_PIC FPGA, 1.2V PIC FPGA, IC4401
152
PF_3.3V_GAM 3.3V_GAM GAMMA, 3.3V Gamma 3.3V, IC401
151 PF_2.5V_GAM 2.5V_GAM GAMMA, 2.5V Gamma 2.5V, IC401
251
PF_1.8V_GAM 1.8V_GAM GAMMA, 1.8V Gamma 1.8V, IC401
52
PF_3.3V_SH 3.3V_SH SH, 3.3V S&H 3.3V, IC501-IC1561
150 PF_15.5V_GAM 15.5V_GAM GAMMA, 15.5V Gamma 15V, IC401
216
PF_5V_PJ PJNET_5V PJNET, S5V PJ-NET 5V
237
PF_9V_LNS 9V_LNS LENS, 9V Lens Drive 9V
215
PF_15V_LNS 15V_LNS LENS, 15V Lens Drive 15V
236
PF_6V_MAIN S6V MAIN, 6V Main S6V
235
PF_3.3V_MAIN S3.3V MAIN, 3.3V Main S3.3V
234 PF_12V_FILTER 12V FILTER, 12V Filter Drive 12V
233
PF_S5V_AV S5V_AV AV, S5V AV S5V
232
PF_S-6V_AV -6V AV, S-6V AV S-6V
185 PF_25V_4LCD 25V YE, 25V Optical Filter Drive Power
212
PF_FN904 FN904 POWER & LOCK FN904, 13V FN904 Power & Lock
211 PF_FN902 FN902 POWER & LOCK FN902, 13V FN902 Power & Lock
147 PF_FN901 FN901 POWER & LOCK FN901, 13V FN901 Power & Lock
183 PF_FN908 FN908POWER & LOCK FN908, 13V FN908 Power & Lock
227
PF_FN905&FN906 FN905,FN906 POWER & LOCK FN905&6 13V FN905&FN906 Power & Lock
201
PF_FN903 FN903 POWER & LOCK FN903, 13V FN903 Power & Lock
226
PF_FN907 FN907 POWER & LOCK FN907, 13V FN907 Power & Lock
202
PF_9V_AUDIO 9V AUDIO AUDIO, 9V 9V AUDIO
IC4801
TE7783
61 PF_S1.2V_FRT S1.2V_FRT SWFPGA, 1.2V SW FPGA1.2V, IC5201
62
PF_S5V_MAIN S5V MAIN, S5V Main S5V Power
63 PF_5V_MAIN 5V MAIN, 5V Main 5V Power
IC301
PW392
343 FILTER DET FILTER CONDITION DETECT FILTER, DET Filter Cartridge is not installed
388 MOTOR_POSI MOTOR ERROR DETECT MOTOR, TIMEOUT Filter Motor Error
281
PRESS_SENS PRESSURE SENSOR DETECT PRESS, ERROR Pressure is less than 500mmHg
IC5201
- - - FPGASW, CONFIG IC5201 Configuration Error
IC4401 - - - FPGAFINE, CONFIG IC4401 Configuration Error
IC4401
292
391
SHUTTER_POS1
SHUTTER_POS2
SHUTTER POSITION SW SHUTTER, ERROR Shutter Operation Error

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
