Sanyo PLC-XP200L - Lamp Control Stage

-68-
Chassis Description
SW1861
LAMP COVER-SW
IC301
SYSTEM
CONTROL
&
SCAN
CONVERTER
<PW392>
LAMP LP900
AC
SW905
THERMAL
PROTECTOR
A902
POWER
A901
LAMP
BALLAST
Q1861
LB_PW_UART
Q331
PFC_SW_EX
PW_LB_UART
LAMP_SWIN_EX
LAMP_SWIN
PFC_SW
IC1853
INVERTER
IC1871
COVER SW.
1 2
32 12 356 445 145
25 25
5 1 4 5 1 4
3 1 3 1
K10B
CN6A
CJ1
CJ2
K6C
K6A K6B
K8K K8B
35
8
119
POWER-ON:H POWER-ON:H
MAIN
Lamp control stage
