Sanyo PLC-XP200L Service Manual

-48-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
50 2:2pull down setting
0 22Film Mode Sensitivity Film Detection Sensitivity <FILMSTVT22> 1 - 5 4
1 22Film Mode Threshold Low <FILMTHRD22A> 0 - 1023 80
2 22Film Mode Threshold High <FILMTHRD22B> 0 - 1023 120
3 Video Motion Window Start X <VOFSTARX> 0 - 255 10
4 Video Motion Window Stop X <VOFSTOPX> 0 - 255 10
5 Video Motion Window Start Y <VOFSTARY> 0 - 255 10
6 Video Motion Window Stop Y <VOFSTOPY> 0 - 255 10
51 2:3pull down setting
0 Global Motion Sensitivity Film Detection Sensitivity <FILMSTVT23> 1 - 5 4
1 Video Motion Sensitivity Film Detection Sensitivity <VOFSTVT> 1 - 5 4
2 Video Motion Threshold Low <VOFTHRDA> 0 - 1023 120
3 Video Motion Threshold High <VOFTHRDB> 0 - 1023 180
4 Global Motion 23Film Threshold <FILMTHRD23> 0 - 1023 100
5 Global Motion Window Start X <GMDSTARX> 0 - 255 10
6 Global Motion Window Stop X <GMDSTOPX> 0 - 255 10
7 Global Motion Window Start Y <GMDSTARY> 0 - 255 10
8 Global Motion Window Stop Y <GMDSTOPY> 0 - 255 10
55 LTI / CTI
0 Video Enhancement Enable VEHEN 0 - 1 1
1 DLTI Gain DLTIGAIN 0 - 15 3
2 DLTI Frequency DLTIFREQ 0 - 3 2
3 Bypass Anti-Alias Filter DTIBYPASSAAL 0 - 1 0
4 Lower DCTI Frequency LOWERDCTIFREQ 0 - 1 1
5 DCTI Gain DCTIGAIN 0 - 15 4
6 DCTI Frequency DCTIFREQ 0 - 3 0
7 Color Shift Limit COLORSHIFTLMT 0 - 3 3
60 Sub Image
0 Center Contrast
Group
Composite / S-Video / Component / Digital /D-RGB-Video
/AnalogRGB / RGB-Video / HDCP-PC /HDCP-AV /SCART/ PJ-
Net
Value = (Menu Value - Menu Center) x Alpha / 10 + Center
(Effective Range)
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0 (Dummy)
WB R/G/B [Max] 1023 [Min] 0
BB R/G/B [Max] 1023 [Min] 0
Fixed Sharpness Up/Down [Max] 37 [Min] 0
0 - 1023
578/578/578/492/492/589
/589/492/492/589/492
1 Center Brightness 0 - 1023
512/512/512/512/512/493
493/512/512/493/512
2 Center Color 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
3 Center Tint 0 - 180 90/90/90/90/90/90 / 90/90/90/90/90
4 Fixed Sharpness(Up Scaling) 0-37 8/8/8/8/8/8/ 8/8/8/8/8
5 Fixed Sharpness(Down Scaling) 0-37 8/8/8/8/8/8/ 8/8/8/8/8
6 Center Sharpness(No FPGA) 0-37 16/16/16/16/16/16/ 16/16/16/16/16
7 Center WB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
8 Center WB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
9 Center WB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
10 Center BB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
11 Center BB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
12 Center BB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
13 Alpha Contrast 0 - 1000 60/60/60/60/60/60/ 60/60/60/60/60
14 Alpha Brightness 0 - 1000 90/90/90/90/90/90/ 90/90/90/90/90
15 Alpha Color 0 - 1000
140/140/140/140/140/140
/140/140/140/140/140
16 Alpha Tint 0 - 1000 10/10/10/10/10/10/ 10/10/10/10/10
17 Alpha Sharpness 0 - 1000 10/10/10/10/10/10/ 10/10/10/10/10
18 Alpha WB Red 0 - 1000 40/40/40/40/40/40/ 40/40/40/40/40
19 Alpha WB Green 0 - 1000 40/40/40/40/40/40/ 40/40/40/40/40
20 Alpha WB Blue 0 - 1000 40/40/40/40/40/40/ 40/40/40/40/40
21 Alpha BB Red 0 - 1000 20 /20/20 /20/20 /20/ 20/20/20/20/20
22 Alpha BB Green 0 - 1000 20 /20/20 /20/20 /20/ 20/20/20/20/20
23 Alpha BB Blue 0 - 1000 20 /20/20 /20/20 /20/ 20/20/20/20/20
80 FPGA
0 Software version FPGA Software Version Info. Read only
1 Hardware version FPGA Software Version Info. Read only
2 Horizontal total Read only
3 Vertical total Read only

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
