Sanyo PLC-XP200L Service Manual

-49-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
4 Horizontal resolution Read only
5 Vertical resolution Read only
6 Color manager enable 0: Disable/1: Enable 0 ~ 1 1
7 Y range 0 ~ 32 8
8 Hue range 0 ~ 30 10
9 Gain range 0 ~ 50 30
10 Min slope 0 ~ 10 3
11 Max slope 10 ~ 30 18
12 Convergence 1 ~ 5 3
13 Same hue 1 ~ 10 3
14 UV normaliz 0 ~ 64 5
15 Min Y 0 ~ 127 0
16 Max Y 128 ~ 255 255
17 Area big change 0 ~ 4095 67
18 Area small change 0 ~ 4095 67
19 Area change sense 0 ~ 4095 150
20 Same Y 0 ~ 63 24
21 Conv Y 0 ~ 127 64
22 WB Limit 0 0 ~ 255 4
23 WB Limit 1 0 ~ 255 40
24 WB Limit 2 0 ~ 255 41
25 WB Limit 3 0 ~ 255 41
26 WB Limit 4 0 ~ 255 41
27 WB Limit 8 0 ~ 255 41
28 UV DLT 0 ~ 31 3
29 UV Gain 0 ~ 2047 1030
30 UV Shift 0 ~ 32767 6180
31 WB Limit Out 0 ~ 255 20
32 WB Limit In 0 ~ 255 14
33 WB Limit PtFlg 0 ~ 1 1
34 Set for SHOW, Setd Setting 0: Normal, 1: SHOW, 2 SHOW, 3: Test 0 ~ 3 0
100 CLK_SHIFT SW-FPGA : CLK_SHIFT : LVSClock Phase Adj. -64 ~ 63 0
81 FPGA - Ye Overlay
0 DEC_R Ye Overlay Control: R Coefficient(-) 0 ~ 255 130
1 DEC_G Ye Overlay Control: G Coefficient(-) 0 ~ 255 40
2 B_RATIO Ye Overlay Control: B Coefficient(+) 0 ~ 255 15
3 SAT_SLOPE Ye Overlay Control: Coefficient(Saturation) 0 ~ 255 71
4 R_SLOPE Ye Overlay Control: Coefficient(R-tint) 0 ~ 255 70
5 G_SLOPE Ye Overlay Control: Coefficient(G-tint) 0 ~ 255 77
6 LUM_MAX Ye Overlay Control: Coefficient(Max) PC-Standard 0 ~ 255 255
7 LUM_MAX Ye Overlay Control: Coefficient(Max) PC-Real 0 ~ 255 255
8 LUM_MAX Ye Overlay Control: Coefficient(Max) AV-Standard 0 ~ 255 255
9 LUM_MAX Ye Overlay Control: Coefficient(Max) AV-Cinema 0 ~ 255 255
10 LUM_MIN Ye Overlay Control: Coefficient(Min) PC-Standard 0 ~ 255 0
11 LUM_MIN Ye Overlay Control: Coefficient(Min) PC-Real 0 ~ 255 0
12 LUM_MIN Ye Overlay Control: Coefficient(Min) AV-Standard 0 ~ 255 0
13 LUM_MIN Ye Overlay Control: Coefficient(Min) AV-Cinema 0 ~ 255 0
14 YE_SENS Ye Overlay Control: Time Constant 0 ~ 255 4
15 YE_TESTFLG Ye Overlay Control: Test Flag 0 ~ 255 3
16 DAC_MAX Not used 0 ~ 255 255
17 DAC_MIN Not used 0 ~ 255 0
18 DAC_UseMin DAC Level at Power ON 0 ~ 255 0
19 YE_FIX_VAL Ye Overlay Control: Manual value at Fix PC-Standard 0 ~ 255 60
20 YE_FIX_VAL Ye Overlay Control: Manual value at Fix PC-Real 0 ~ 255 60
21 YE_FIX_VAL Ye Overlay Control: Manual value at Fix AV-Standard 0 ~ 255 60
22 YE_FIX_VAL Ye Overlay Control: Manual value at Fix AV-Cinema 0 ~ 255 60
23 DAC_RangeMax DAC Range Max. 0 ~ 255 255
24 DAC_RangeMin DAC Range Min. 0 ~ 255 32
25 P_PWM_WIDTH Panel PWM: Output Width 0 ~ 16383 376
26 DAC_LEVEL(YEAUTO_YE_LVL) DAC Level Forced Setting(Ye Auto) 0 ~ 255 255
27 YE_APLUsed APL Used Rate(%) at YE_VAL=100% 0 ~ 255 20
28 YE_APLOff APL Max(%) at YE_VAL= 0% 0 ~ 255 0
29 YE_FIX_VAL_SW Ye Overlay Control: Manual value Select at Fix PC-Standard 0 ~ 1 1
30 YE_FIX_VAL_SW Ye Overlay Control: Manual value Select at Fix PC-Real 0 ~ 1 1
31 YE_FIX_VAL_SW Ye Overlay Control: Manual value Select at Fix AV-Standard 0 ~ 1 1
32 YE_FIX_VAL_SW Ye Overlay Control: Manual value Select at Fix AV-Cinema 0 ~ 1 1
33 YE_APL_A0 Min: X-Cordinate at Point 0(%) 0 ~ 127 30
34 YE_APL_A1 Min: X-Cordinate at Point 1(%) 0 ~ 127 62
35 YE_APL_A2 Min: X-Cordinate at Point 2(%) 0 ~ 127 75

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
