Sanyo PLC-XP200L Service Manual

-50-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
36 YE_APL_A3 Min: X-Cordinate at Point 3(%) 0 ~ 127 90
37 YE_APL_A4 Min: X-Cordinate at Point 4(%) 0 ~ 127 100
38 YE_GAIN_A0 Min: Y-Cordinate at Point 0 (%) -256~ 255 -20
39 YE_GAIN_A1 Min: Y-Cordinate at Point 1(%) -256~ 255 -12
40 YE_GAIN_A2 Min: Y-Cordinate at Point 2(%) -256~ 255 -4
41 YE_GAIN_A3 Min: Y-Cordinate at Point 3(%) -256~ 255 13
42 YE_GAIN_A4 Min: Y-Cordinate at Point 4(%) -256~ 255 30
43 YE_APL_B0 Max: X-Cordinate at Point 0(%) 0 ~ 127 8
44 YE_APL_B1 Max: X-Cordinate at Point 1(%) 0 ~ 127 19
45 YE_APL_B2 Max: X-Cordinate at Point 2(%) 0 ~ 127 30
46 YE_APL_B3 Max: X-Cordinate at Point 3(%) 0 ~ 127 38
47 YE_APL_B4 Max: X-Cordinate at Point 4(%) 0 ~ 127 45
48 YE_GAIN_B0 Max: Y-Cordinate at Point 0(%) -256 ~ 255 20
49 YE_GAIN_B1 Max: Y-Cordinate at Point 1(%) -256 ~ 255 26
50 YE_GAIN_B2 Max: Y-Cordinate at Point 2(%) -256 ~ 255 43
51 YE_GAIN_B3 Max: Y-Cordinate at Point 3(%) -256 ~ 255 70
52 YE_GAIN_B4 Max: Y-Cordinate at Point 4(%) -256 ~ 255 100
53 YE_APL_C0 Detect Coefficient: X-Cordinate at Point 0(%) 0 ~ 127 7
54 YE_APL_C1 Detect Coefficient: X-Cordinate at Point 1(%) 0 ~ 127 25
55 YE_APL_C2 Detect Coefficient: X-Cordinate at Point 2(%) 0 ~ 127 40
56 YE_APL_C3 Detect Coefficient: X-Cordinate at Point 3(%) 0 ~ 127 50
57 YE_APL_C4 Detect Coefficient: X-Cordinate at Point 4(%) 0 ~ 127 60
58 YE_EXP_C0 Detect Coefficient: Y-Cordinate at Point 0(%) 0 ~ 511 300
59 YE_EXP_C1 Detect Coefficient: Y-Cordinate at Point 1(%) 0 ~ 511 278
60 YE_EXP_C2 Detect Coefficient: Y-Cordinate at Point 2(%) 0 ~ 511 207
61 YE_EXP_C3 Detect Coefficient: Y-Cordinate at Point 3(%) 0 ~ 511 120
62 YE_EXP_C4 Detect Coefficient: Y-Cordinate at Point 4(%) 0 ~ 511 100
63 YEOFF_YE_SW
Data Select at Ye Off
0:Fixed :YEOFF_YE_LVL, 1:DAC Calc Result: g_ans_fixval
0 ~ 1 1
64 YEOFF_YE_LVL Forced DAC Level Set for Ye Off 0 ~ 255 255
100 CXA7009R
0 G SIG Center 0 ~ 63 34
1 B SIG Center 0 ~ 63 34
2 R SIG Center 0 ~ 63 34
3 G Gain Control 0 ~ 255 199
4 B Gain Control 0 ~ 255 199
5 R Gain Control 0 ~ 255 199
6 G Bright Control 0 ~ 255 0
7 B Bright Control 0 ~ 255 0
8 R Bright Control 0 ~ 255 0
9 G VCOM Control 0 ~ 255 100 * Common voltage adj.
10 B VCOM Control 0 ~ 255 100 * Common voltage adj.
11 R VCOM Control 0 ~ 255 100 * Common voltage adj.
12 G SID Control A 0 ~ 255 12
13 B SID Control A 0 ~ 255 12
14 R SID Control A 0 ~ 255 12
15 G SID Control B 0 ~ 255 127
16 B SID Control B 0 ~ 255 127
17 R SID Control B 0 ~ 255 127
18 G FRINV 0 ~ 1 0
19 B FRINV 0 ~ 1 0
20 R FRINV 0 ~ 1 0
101 CXD3540_TG
0 SCANM 0 ~ 3 2
1 FRPM 0 ~ 2 2 * Common voltage adj.
2 SCAN_SEL 0 ~1 1
3 HP 0 ~ 2047 14
4 VP_G 0 ~ 255 4
5 SHP_R 0 ~ 127 58
6 SHP_G 0 ~ 127 58
7 SHP_B 0 ~ 127 58
8 FRP_HP 0 ~ 2047 49
9 PRG_U 0 ~ 1023 49
10 PRG_D 0 ~ 1023 112
11 HST_R_PF 0 ~ 127 22
12 HST_R_PC 0 ~ 127 7
13 DCK1_R_WA 0 ~ 127 11
14 DCK1_R_F 0 ~ 127 48

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
