Sanyo PLC-XP200L Service Manual

-84-
Control Port Functions
PIN PORT SIGNAL FUNCTIOM I/O NOTE
A1 RX2-PW DVI Input I
A3 RX1-PW DVI Input I
A5 RX0-_PW DVI Input I
A7 RXC-_PW DVI Input I
A18 HSOUT H SYNC Input I
A19 LENS_L_POSI_EX Lens Shift L Detect Input I
A20 PW_SDA3 IIC Bus 3 I/O
A23 LAMP_DET Lamp Detect Input I
A25 DDC_SW_CPU DDC Switch Control O
A27 KEY11 Keypad Input I
A28 KEY31 Keypad Input I
A29 KEY03 Keypad Input I
B1 RX2+_PW DVI Input I
B3 RX1+_PW DVI Input I
B5 RX0+_PW DVI Input I
B7 RXC+_PW DVI Input I
B18 IN0HS H SYNC Input I
B19 LENS_R_POSI_EX Lens Shift R Detect Input I
B20 PW_SCL3 IIC Bus 3 I/O
B22 OUT_SW Monitor Output Switch Control O H: Monitor Out
B23 TRM2 Long Cable Switch O H: Long Cable
B24 -BNC/RCA_CPU BNC/RCA Switch O H: BNC L: RCA
B25 KS_CRSTN PW610 Reset Signal Output O
B27 KEY21 Keypad Input I
B28 KEY02 Keypad Input I
B29 POWER ON Keypad Input I
C18 IN0VS V Sync Input I
C19 LENS_BOT_EX Lens Shift Bottom Detect Input I
C22 IN1/IN2 INPUT 1/INPUT2 Switch O H: INPUT1 L: INPUT2
C23 TRM1 Long Cable Switch O H: Long Cable
C24 DSUB_DDC_SW_CPU DDC Switch Control (DSUB) O
C25 SW_1.8VGAM_EX SW_1.8V Switch output O H: On
C26 RST_S&H_SH Reset For Sample&Hold IC O
C27 KEY01 Keypad Input I
C28 ON_15V_EX On_15V Switch Output O H: On
C29 LAMP_SWIN_EX LAMP Drive Switch Output O H: On
C30 PFC_SW_EX Fan Control Switch Output O H: On
D18 LENS_C_POSI_EX Lens Shift Center Detect Input I
D19 LENS_TOP_EX Lens Shift Top Detect Input I
D21 ON_25V 25V Drive Signal Output O H: On
D22 FILTER_DET Filter Detect Input I
D25 SW_2.5VGAM_EX SW_2.5V Drive Signal Output O H: On
D26 SW_1.8V_KS_EX SW_1.8V Drive Signal Output(KS) O H: On
D27 SW_2.5V_KS_EX SW_2.5V Drive Signal Output(KS) O H: On
D30 POWER_LED Power LED Drive Output O H: On
E2 Reset IC I
E25 SW_3.3VGAM_EX SW_3.3V Drive Signal Output H: On O H: On
E26 FILTER_LED Filter LED Drive Output O H: On
E27 SHUTTER_LED Shutter LED Drive Output O H: On
E28 READY_LED Ready LED Drive Output O H: On
E29 TEMP_LED Warning LED Drive Output O H: On
E30 LAMP_REP_LED Lamp Replace LED Drive output O H: On
F26 MUTE_EX Mute Output O H: Mute
G4 HDCP_CLK HDCP IIC Bus I/O
G5 HDCP_DATA HDCP IIC Bus I/O
J1 VIDEO Composite Video Signal I
K1 S_C S-Video C Signal I
K3 S_Y S-Video Y Signal I
K26 ZOOM-_EX Zoom- Drive Output O
K28 LAMP_TEMP Lamp Temp Sensor Input I
K29 FOCUS+_EX Focus+ Drive Output O
K30 FOCUS-_EX Focus- Drive Output O
L26 PW_SDA0 IIC Bus 0 I/O
L27 PW_SCL0 IIC Bus 0 I/O
L30 ZOOM+_EX Zoom+ Drive Output O
M26 LB_PW_UART UART for Lamp Ballast I/O
M27 PW_LB_UART UART for Lamp Ballast I/O
M29 PW_SDA2 IIC Bus 2 I/O
M30 PW_SCL2 IIC Bus 2 I/O
N1 SCART Blue Input I
System Control I/O Port Functions (PW392, IC301)

Sanyo PLC-XP200L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Bundled software	User Manual (CD ROM)
I/O ports	DVI-D (digital/HDCP) D-Sub15 (RGB/SCART-RGB) 5 x BNC (RGBHV/Composite/Y-Pb/Cb-Pr/Cr) 3 x RCA (Video/Y-Pb/Cb-Pr/Cr) Mini DIN 4 (S-Video) 3.5 mm Stereo Jack D-Sub15 D-Sub9 (RS232) 3.5 mm Stereo Jack (cable remote control) USB type B
Compatibility	UXGA SXGA SXGA+ WXGA XGA S-VGA VGA Mac
Dimensions (WxDxH)	370 x 440 x 187 mm
Power requirements	100 - 240 V
Power consumption (standby)	24.5 W
Power consumption (typical)	499 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Placement	Ceiling

Weight and Dimensions

Weight	11400 g
Package weight	15900 g
